Indoor // hard standing
19ft Electric Scissor Lift Hire – JLG ES1932
JLG ES1932
19ft JLG electric scissor lift, 7.8m working height, 230kg capacity, non-marking tyres and zero inside turning radius — the go-to indoor machine.
Working height
7.8 m
Platform height
5.8 m
Power
Electric
Width
0.81 m
Specification sheetDownload Specification sheet
Also available to buy
19ft Electric Scissor Lift For Sale – JLG ES1932
Machines sell subject to prior sale. Condition, hours and price are confirmed on enquiry; no finance, warranty or delivery is included unless agreed in writing.
Price
Price on application
Enquire About This Machine
Send us your requirements and an Equip Hire equipment expert will contact you to confirm whether this machine is suitable for your application.
All machines for saleOverview
About the 19ft Electric Scissor Lift Hire – JLG ES1932
The JLG ES1932 is a compact 19ft electric scissor lift built for indoor and hard-surface work. It reaches a 7.8m working height (5.8m platform), carries 230kg on the platform plus 120kg on the roll-out deck extension, and fits through a standard doorway at 0.81m wide. Non-marking tyres, a zero inside turning radius and quiet electric drive make it ideal for fit-outs, maintenance and retail work on finished floors. Runs on 4 x 6V batteries with an onboard 27A charger.
Where it works
Best-fit jobs and sites
- Indoor fit-outs, electrical and HVAC, retail and warehouse maintenance, ceiling and services work on finished slabs.
Good to confirm: Solid non-marking tyres and low clearance — smooth, firm surfaces only. Not for outdoor rough ground. An online listing cannot replace a site assessment, so tell us the job and we will confirm suitability.
Specifications
Full specifications
Grouped for quick scanning — a row appears once its figure is verified for this machine. The manufacturer spec sheet always takes precedence.
Reach & platform3 specs
- Working height
- 7.8 m
- Platform height
- 5.8 m
- Extension deck
- 0.9m roll-out, 120kg
Capacity1 spec
- Platform capacity
- 230
Dimensions2 specs
- Overall width
- 0.81 m
- Turning radius
- 1.7
Performance4 specs
- Gradeability
- 25
- Terrain type
- Indoor // hard standing
- Indoor use
- Yes
- Outdoor use
- Limited
Power & drive5 specs
- Power source
- Electric
- Battery
- 4 x 6V 220Ah
- Charging
- 27A onboard (240V outlet)
- Drive type
- 2WD
- Tyre type
- Non-marking solid
Machine & transport5 specs
- Manufacturer
- JLG
- Model
- ES1932
- Machine weight
- 1550
- Customer pickup
- Delivery only
- Delivery
- Quoted by suburb & access
Dimensions at a glance
The numbers that decide access
- Machine width
- 0.81 m: fits a standard single doorway (~0.82 m clear); measure your narrowest opening
Drawn to scale from this machine's stored specifications. The manufacturer spec sheet (below) governs.
Delivery, access and running
Delivery is quoted by suburb, site access and transport requirements. Tell us the tightest access width on site if the machine must pass through gates, doorways or between structures.
Licence and competency: Scissor-type EWP. No high-risk work licence required in NSW; EWPA Yellow Card (SL) is the accepted operator competency.
Hire period: Hire runs from delivery or pickup until off-hire is confirmed. Rates are quoted for your dates, suburb and machine together; see our hire terms for responsibilities during the hire.
Charging this machine
- Batteries
- 4 x 6V 220Ah
- Charger
- 27A onboard (240V outlet)
- Our fleet guidance
- Charge overnight (about 8 hours) from a standard outlet for a full day's work. Runtime depends on battery condition, drive distance and lift cycles. Ask us if your job runs long shifts.
- Confirm a live, accessible power outlet near where the machine parks each night. A machine left away from power starts tomorrow flat.
- Plug in at the end of every shift, not "when it gets low"; opportunity charging at breaks helps on heavy days.
- Charge in a ventilated area and keep the charger connections dry.
Pre-start checks, every day
Every Equip Hire machine is function-tested before delivery, and every operator still checks the machine before each shift. This is the baseline we use; the machine's own logbook and check sheet govern.
Walk around
- Tyres, wheels and structure: damage, cracks, leaks
- Scissor stack / boom, pins and hoses: no visible damage or hydraulic leaks
- Decals, capacity plate and rails in place; gates close properly
- Work area: overhead power lines, holes, slopes, other traffic
Power on
- Battery state of charge: enough for the shift
- Ground and platform controls both operate correctly
- Emergency stop and horn work from both stations
Function test
- Raise, lower and drive at low height before working
- Emergency lowering: know where it is and that it works
- Tilt / overload alarms not showing faults
Any fault: tag it out and call us on 0472 721 234. Do not operate a machine with a known fault. Based on manufacturer pre-start requirements and SafeWork NSW guidance.
Before it arrives
- Measure the route, not the door. Every gate, corridor and lift on the way to the work area: handles, hinges, bollards and stored materials all eat clearance.
- Confirm the floor. Ground-bearing slab is fine; suspended slabs, mezzanines and raised floors need the wheel loads checked against the floor rating.
- Clear the work zone. Overhead services, sprinkler heads and light fittings at working height; exclusion for people below.
- Delivery space. Room for the truck to stop and unload safely. Tell us about docks, driveways and height limits when you book.
- Power point. A live outlet near overnight parking, so every day starts charged.
Mistakes we see weekly
- Booking on ceiling height instead of the actual task height. Measure to the work, then add nothing "just in case".
- Quoting the nominal door size instead of the clear opening. An 820 mm door leaf are not 820 mm once the door stop is counted.
- Assuming the machine can cross "a bit of lawn". Wheeled machines rut turf and bog in soft ground; say so and we'll send tracks.
- Leaving induction and permit requirements to delivery morning. Shopping centres and managed sites need paperwork before the truck arrives.
Documents
Operation manualDownload Operation manual
Pre-start checklistDownload Pre-start checklist
Risk assessmentDownload Risk assessment
